From any starting point
Bring an idea, a sketch, a photo, an old sample or a full CAD file. We take it from there.
Home / Design and prototyping
General Plastic Industries LLP (GPI) turns your idea, sketch or sample into a part that is ready to mould. We design on CAD, suggest changes that make the part stronger and cheaper to mould, and make prototypes by FDM, SLA, SLS or DMLS. Then the same team builds the mould and makes your parts.
Why GPI
A part can look perfect on screen and still be hard to mould. It may sink, bend or crack in use. We have moulded plastic parts since 1968, so we design for the mould from day one. That saves you mould changes, time and money later.
Bring an idea, a sketch, a photo, an old sample or a full CAD file. We take it from there.
We check walls, draft, ribs and gates before the design is final. Fewer mould changes later.
We remove or change features that could fail in the field from weak strength.
The same team designs the part, builds the mould and moulds it. Nothing is lost between firms.
What we do
Pick one service or all of them. Most clients use us from the first sketch to the first production lot.
We shape your idea into a real design on CAD, with the right size, strength and look.
Have an old part but no drawing? We measure it and rebuild it as a clean 3D model.
We review your design and suggest changes that cut mould cost and avoid defects.
FDM, SLA, SLS and DMLS prototypes so you can see, hold and test the part.
We redesign metal or glass parts in plastic to cut weight and cost. See metal to plastic.
When the design is final, our tool room builds the mould and we mould the parts.
Prototyping
Each method suits a different need. We suggest the best one for what you want to test: look, fit, or strength.
| Method | How it works | Best for |
|---|---|---|
| FDM | Builds the part from melted plastic thread, layer by layer. | Quick, low-cost models to check size and shape. |
| SLA | A light cures liquid resin, one thin layer at a time. | Smooth, fine detail. Good for show models and fit checks. |
| SLS | A laser fuses nylon powder into a solid part. | Strong, working parts with snap fits and clips. |
| DMLS | A laser fuses metal powder into a solid metal part. | Metal prototypes and inserts. |
A prototype is close to the final part but not the same. Moulded plastic, made in a steel mould, is stronger and has a better finish.
Our process
Six clear steps take you from an idea to parts in your hand. You approve each step.
Send a sketch, photo, sample or CAD file. Tell us what the part must do, how many you need and your target cost.
We turn the idea into a 3D model on CAD and share it with you.
We check walls, draft, ribs, undercuts and gates. We suggest changes that make the mould simpler and the part stronger.
We make a prototype by FDM, SLA, SLS or DMLS, so you can see and hold the part.
You test look, fit and function. We update the design until you are happy.
We build the injection mould in our tool room and start moulding your parts.
DFM review
Small changes on the drawing save money for the whole life of the mould. These are the points we check on every part.
Even walls cool evenly. Thick spots cause sink marks, bending and long cycles.
A slight taper lets the part come out clean, with no drag marks.
Thin ribs add strength without sink. Hollow bosses cool faster.
We remove hooks where we can. Each one needs a slider, which adds cost.
We place them away from faces people see, so the part looks clean.
We match the grade to heat, strength and cost. See our plastics guide.
Prototype or not
A prototype costs a little now and can save a lot later. A change in steel costs far more than a change on a prototype.
A new shape or a new product should be seen and held before the mould is made.
Parts that snap, screw or slide into other parts need a fit check first.
A proven part made again, or a simple change, can often go straight to the mould.
Read more: How to know if you need a prototype.
Get a quote
Send us what you have. Even a rough sketch is enough to start. Your ideas and drawings stay private.
A sketch, photo, old sample, 2D drawing or 3D file (STEP or IGES).
Where it goes, what it holds, and any heat or load it must take.
Prototypes only, a small batch, or yearly production.
Your price goal per part and when you need it.
FAQ
Short, clear answers to the questions buyers ask most.
Product design and prototyping is the work of turning an idea into a real part. A designer draws the part on CAD. A prototype is then made so you can see, hold and test it. At GPI, the same team then builds the mould and makes the parts.
Yes, GPI can design a plastic part from a sketch, a photo or just an idea. We ask what the part must do, then build a 3D model on CAD. We share it with you and change it until it is right, before any mould is made.
Reverse engineering of a plastic part means making a new drawing from an existing part. We measure the old part and rebuild it as a clean 3D model. This helps when a drawing is lost or a part needs to be improved.
The best prototype method depends on what you want to test. FDM is quick and low cost for shape checks. SLA gives smooth, fine detail. SLS makes strong nylon parts for fit and function. DMLS makes metal parts. GPI suggests the right method for your part.
No, a 3D printed prototype is close to the moulded part but not the same. A moulded part is usually stronger and has a better finish, because it is made in a steel mould. Prototypes are best for checking shape, fit and basic function.
Design for manufacturing (DFM) in injection moulding is a review that makes a part easy and cheap to mould. It checks walls, draft angles, ribs, undercuts and the gate position. GPI does a DFM review on every part before the mould is made.
Design and prototyping time depends on how complex the part is and how many changes you need. A simple part moves fast. A new product with many parts takes longer. GPI gives a date for each step after we see your idea or drawing.
Yes, GPI keeps your ideas and drawings private. We use them only to design, quote and make your parts. If you need a formal agreement before sharing, tell us when you first contact us.
Yes, GPI converts metal and glass parts to plastic. We pick a suitable engineering plastic and redesign the part for moulding. This can cut weight and cost. We test the new design with a prototype before making the mould.
You can get plastic product design and prototyping at General Plastic Industries in Delhi. We are at Plot No. 67, Rajasthani Udyog Nagar, near Jahangirpuri Metro, G.T. Karnal Road, Delhi 110033. Call +91-9999 600 619 or email sales@generalplastic.in.
Send your sketch, sample or CAD file. Our engineers will reply with the next steps, time and cost. We are ISO 9001:2015 and ISO 45001:2018 certified and RoHS compliant, and we use Scientific Moulding.
