Preparing drawings and specifications for an injection mould quote

10 Things to Prepare When Requesting Injection Mould (Mold) Quotes

Short answer: To get an accurate injection mould quote, send a 3D CAD model and 2D drawing with tolerances, the plastic material, expected volumes, any prototype needs, your target date for first samples, the quality standards and any secondary operations. GPI in Delhi then quotes the mould cost, part price and lead time separately, and keeps your drawings confidential.

Plastic Injection Mold Quotes: 10 Essential Preparations
When seeking quotes for plastic injection molds, having detailed and precise information ready can ensure you receive accurate and competitive estimates. Here are ten key things to prepare when requesting plastic injection mold quotes.


1. Project Specifications

Begin with a comprehensive description of your project. Detail the design, dimensions, and purpose of the part you need to be molded. Include any specific requirements such as tolerances, surface finish, and material type. Clear project specifications enable suppliers to provide precise quotes.


2. CAD Files

Provide detailed CAD (Computer-Aided Design) files of your part. These files are crucial for the mold makers to understand the geometry and complexity of the part. Most suppliers prefer 3D models in formats like .STP or .IGS, as they allow for thorough analysis and accurate cost estimation.


3. Material Selection

Specify the type of plastic material you intend to use. Different materials have varying properties and costs, which can significantly affect the quote. If you’re unsure about the best material for your application, ask potential suppliers for recommendations based on your part’s requirements.


4. Production Volume

Indicate the estimated production volume for your part. The number of units you plan to produce can influence the type of mold required and the associated costs. High-volume production might necessitate more durable, multi-cavity molds, whereas low-volume runs might use simpler, single-cavity molds.


5. Prototype Requirements

If you need prototype parts before committing to full-scale production, mention this in your quote request. Prototyping can help validate the design and functionality of your part, but it also adds to the overall cost and timeline.


6. Lead Time Expectations

Provide your expected lead times. Clearly state when you need the initial mold and subsequent parts. If you have strict deadlines or need expedited services, suppliers need to know this upfront to plan accordingly and quote appropriately.


7. Quality Standards

Specify any quality standards or certifications your parts must meet. This might include industry-specific standards like ISO, FDA, or automotive requirements. High-quality standards might necessitate additional inspection and testing, impacting the overall cost.


8. Secondary Operations

Mention any secondary operations that might be required after molding, such as painting, plating, or assembly. These additional processes can affect the overall quote, as they require extra time and resources.


9. Supplier Experience

Inquire about the supplier’s experience with similar projects. A supplier with relevant experience can offer valuable insights and might be able to suggest cost-saving measures without compromising on quality. Request case studies or references from projects similar to yours.


10. Budget Considerations

While it’s not always necessary to disclose your exact budget, providing a rough range can help suppliers propose solutions within your financial constraints. This can also facilitate more efficient negotiations and prevent wasted time on quotes that are outside your budget.


Conclusion

By preparing these ten essential pieces of information, you can streamline the process of obtaining accurate and comprehensive quotes for plastic injection molds. Thorough preparation and clear communication ensure you receive the best possible service and value for your project.



GPI quoting facts at a glance

Send towww.generalplastic.in/contact.html, sales@generalplastic.in or WhatsApp +91-9999-600-619
Quote formatMould cost, part price and lead time shown separately
Minimum order quantity2,000 pieces per part
Lead timeAbout 45 days to first samples for a new mould; Express Mould in 15 to 20 days
Part sizeShot weight 1 g to 4 kg
ToleranceCritical features ± 0.1 mm; general dimensions to DIN 16742
MaterialsPA 66, PA 6, PA 4.6, PPS, PES, PBT, POM, PC, alloys, TPU and TPE, including glass-filled grades
ConfidentialityIdeas and drawings kept confidential

Injection mould quotes: frequently asked questions

What should I send to get an injection mould quote?

Send a 3D CAD model and a 2D drawing with tolerances, the material, your expected volumes, prototype needs, target date for first samples, quality standards and any secondary operations such as assembly.

I only have a sample or a sketch. Can I still get a quote?

Yes. GPI's design team can turn an idea, sketch, photo, old sample or CAD file into a part that is ready to mould, including reverse engineering of existing parts.

Does GPI quote the mould and the parts separately?

Yes. GPI's quote shows the mould cost, the part price and the lead time separately, so buyers in Europe, the USA and India can compare quotes like for like.

What is the minimum order quantity?

GPI's minimum order quantity is 2,000 pieces per part.

How long after ordering will I get first samples?

A new mould typically reaches first samples in about 45 days. With GPI's Express Mould offer, a mould can be made in 15 to 20 days.

Are my drawings kept confidential?

Yes. GPI keeps customer ideas and drawings confidential.

How do I send an RFQ to GPI?

Send your drawing, 3D model or RFQ through www.generalplastic.in/contact.html, by email to sales@generalplastic.in or on WhatsApp at +91-9999-600-619.
